Клиника офтальмологии доктора Шиловой
Лазерная коррекция ReLEx SMILE и не только…

Astigmatism — vision as in the kingdom of «crooked mirrors»

Reading time 7 min
Views 1.9K
Original author: Tatiana Shilova
Friends, after a break, we resume publications on vision and technology to restore it. The pause was connected with my workload of operations and participation in conferences: in the near future I will publish a review of the most interesting technical innovations in ophthalmology that were presented at them, and today we will talk about astigmatism.

Что такое астигматизм

Modern statistics depressing. More than half of the world's population suffers from visual impairment, the most common problems are myopia and hyperopia. But ophthalmologists often diagnose another disease, the name of which is unfamiliar to many. Astigmatism is a defect in the optical system of the eye when the sharpness of the image is asymmetric vertically and horizontally. And the parallel rays of light passing through the eye are focused not into a point, but into the “eight”. For a person, this means that the visibility of the image becomes unsharp, and this often applies to both distant and close objects. As a result, instead of a normal image, a person sees a distorted image, in which some lines are clear, others are blurred. An idea of ​​this can be obtained if you look at your distorted reflection in an oval teaspoon.

Ophthalmologists say that almost two thirds of the world's inhabitants face such a problem. But since the degree of astigmatism may be small, many people practically do not feel any discomfort. It is difficult for doctors to identify a clear list of common symptoms indicating that a patient has astigmatism. In each case, they will differ. In the very early stages, it is often confused with tired eyes.

However, quite a few people need special treatment or correction of this disorder with the help of glasses, contact lenses or even surgery.


АAstigmatism is a defect in the optical system of the eye. In this case, the refraction (or reflection) of the rays in different sections of the transmitted light beam is not the same.

As a result, the image of objects becomes blurred, each point of the object is displayed with a blurred ellipse. And the whole picture turns into a so-called Sturm's conoid, as if in a “crooked mirror”. In practice, the main complaint is blurred vision at a distance, often vague near blurring, vagueness and division of objects.
Причины плохого зрения при астигматизме

The course of the rays in the eye with astigmatism looks like.

— I was born that way or ruined my life?

This is the first question that patients ask when they hear this diagnosis for the first time.

Astigmatism may be congenital or acquired, may be stable and progress.

Quite often, astigmatism is a feature of the structure of the cornea at birth, it can even be inherited from parents. If its value affects visual acuity (as a rule, we are talking about astigmatism greater than 1 diopter), then it necessarily requires correction from an early age. Otherwise, the eye sees poorly and develops amblyopia — the “lazy” eye, which is no longer capable of high vision in adulthood. A child with astigmatism, by the way, will never complain to you about poor eyesight — he doesn’t know how to see this well. That is why early examinations by an oculist and wearing glasses, “as prescribed by a doctor”, are so important.

It often happens that a grown-up person is surprised to find out that he has, as it turns out, astigmatism, this is in the case of those not examined in childhood.

Astigmatism may appear already in adulthood as a result of corneal diseases, such as keratoconus, inflammation, trauma and operations.

In any case, it does not appear from working at the computer.

— What is damaged during astigmatism?

First of all, the cause of astigmatism can be two optical systems of the eye — the cornea and lens. When pick up glasses or lenses, then take into account the resulting optical power of these two systems. Please note, usually patients are aware of frequent corneal astigmatism, but they forget about the lens — it can make a difference, for example, in cataracts, when irregularities appear in the lens. “The cornea is flat, but there is astigmatism” — this is it. Often the patient and the optometrist do not bother at all with what is the cause. When selecting points, it is important to correct the rays of light onto the retina using correction. And with surgical correction — this is important.

For a simplified understanding of the essence of the problem, I often explain to patients that the optics of the eye with astigmatism is not like a sphere (a football), but an oval (a rugby ball).

Симптомы и признаки астигматизма

— How is astigmatism different in size, shape and content?

First, the value of astigmatism matters — conditionally up to 1 diopter, astigmatism is considered physiological, weak. That is, as a rule, it does not require correction. But in case he even lowers his vision, alas, he needs to be corrected. The average degree — up to 2 diopters, high — 2-3 diopters and more than 3 diopters — this is a very high astigmatism. There are other classifications, but this one best reflects the effect on defocus.

Secondly, there are two types of corneal astigmatism: regular and irregular.
With regular astigmatism, there are two main refractive perpendicular cross-sectional planes, within which the optical power does not change — weak and strong. In such optics there is at least some regularity, even if the axes are skewed or there is a big difference in their optical power.

Regular astigmatism — in this case, we can distinguish two parts, where the cornea has a different degree of refraction. This type of astigmatism can be corrected with glasses with cylindrical glasses or soft contact lenses.

Irregular astigmatism — in this case, two parts cannot be distinguished, since there are many optical axes. This type usually develops as a result of corneal damage, for example, during an accident (scar tissue is formed), or due to uneven corneal protuberances (keratoconus). Irregular astigmatism is usually poorly corrected, sometimes hard contact lenses or laser effects on the cornea can be useful.

Third, the type of astigmatism depends on the location of the strong axis. If the strong axis is vertical or no more than 30 degrees deviates from the vertical — direct astigmatism. If the strong axis is horizontal ± 30 degrees — astigmatism is reversed. If between — astigmatism with oblique axes. Direct astigmatism slightly increases the depth of focus, the reverse — more impairs visibility, but these both options are corrected well. But the correction of astigmatism with oblique axes with glasses and lenses is worse performed.
Зрение при астигматизме

n astigmatic eyes, there are two perpendicular to the section plane with the greatest and the smallest refractive power.

Ход лучей в глазу при астигматизме

Fourthly, depending on how the focus relates to the retina, astigmatism is divided into myopic (myopic), long-sighted (hypermetropic) and mixed — when one part of the image falls in front of the retina and the part behind the retina. For example, minus two and minus four — then this is complex myopic astigmatism, plus two and plus four — complex long-sighted astigmatism, plus two and minus four — mixed.

Nearsighted astigmatism is indicated by the sign “-”, long-sighted — by the sign “+”, when mixed in the eye there are “+” and “-”.

— How can I suspect astigmatism?

Symptoms of astigmatism are a decrease in vision, sometimes the vision of objects is bent, their split, rapid eye strain at work, headache. Often you may not even suspect that there is such a problem, complaints are so typical — poor vision for distance or near, or at all distances.

— What kind of diagnosis is needed for astigmatism.

Since astigmatism is a defect in optics, then, firstly, the optics of the eye are carefully examined. And the correct conclusion will only ophthalmologist. To do this, we have a number of tests: an autorefractoraketometer study, an aberrometer, a phoroptera with the selection of test lenses to determine visual acuity with maximum correction. A very interesting radiant figure gives an idea of ​​how much astigmatism is present — if you look at the center of the figure from below, some of the lines will be clearer, and some will «blur» with those who have astigmatism.

Звезда Сименса

In the phoropter tests, an ophthalmologist in the arsenal also has a number of techniques to clarify the presence of astigmatism, its axis and size. And this process is always quite time consuming — this can be confirmed by those patients who have done with us, for example, SMILE. Verification of tests with “fogging, cross-cylinders with power and axial samples” for a period of 20-30 minutes.

So, when it is determined that there is still astigmatism, it is necessary to determine “who is to blame” — the cornea or the lens.

A cornea examination should include keratotopography — a study of the relief and optical power of the cornea over its entire area, optical coherent tomography, which determines the thickness, morphology and geometry of the cornea also over the entire area, the study of the posterior surface of the cornea using the Shimflug camera to determine the irregularities of the anterior and posterior cornea, confocal microscopy — the study of the posterior layer of the cornea (endothelium). According to the results of this survey, we can already conclude how healthy the cornea is.

Диагностика астигматизма

This is how the examination on the Scheimflug-camera + Placido rings looks like.

Sometimes astigmatism is associated with the lens — its form, the presence of various opacities in it or a change in its position in space, such astigmatism is called lens-shaped. And it happens that the cornea is irregular and the lens is distorted, then the resultant will affect the final optics as a whole.

We can also study the anterior segment of the eye using ultrasound biomicroscopy in order to examine the parts of the eye that are inaccessible to other methods and measure them.

Yes, by the way, for children there is such a pediatric autorefractometer, which can measure the optics of an eye in a child, without contact, when there is no need to press anything on his forehead and everything happens at a distance of 1.5-2 m. This is important, since children in general are naughty and look badly (or refuse to look at all) to where the ophthalmologist asks. There are not all clinics, as it is expensive. Of course, we have it, called PlusOptix. And late diagnosed astigmatism leads to serious consequences.

Проверка зрения при астигматизме у детей

This survey with PlusOptix

A, has not yet named the old antediluvian method of skiascopy — tracking the movement of the shadow of the reflex from the fundus when the luminescence is inverse with the ophthalmoscope and moving the ruler with lenses. Our grandmothers were diagnosed this way, by the way, quite successfully, if you know how to do it.
Скиаскопия глаза при астигматизме

Method skiascopy.

— How is astigmatism associated with keratoconus

One of the main symptoms appearing in keratoconus is astigmatism. When we diagnose a patient with astigmatism, we must always exclude the latent (forme fruste) or the initial form of keratoconus.

At the beginning of the disease, you may not even suspect about it, even astigmatism may be quite small — 0.5 — 0.75 diopters, however, changes in the cornea are already there and are available only by special methods of examination. Therefore, if you are offered to examine the cornea for its health, this is not a commercial “cheat”, it is worth doing, since the treatment in the initial stages is much more effective than in developed and distant ones.

With keratoconus, it is just about irregular astigmatism, which is bad in advanced stages amenable to correction.

Астигматизм при кератоконусе

This is the keratotopogram at the initial keratoconus.

And in the next post I will talk about how to correct astigmatism, both surgical and non-surgical, as well as what is most important in astigmatism in childhood and adulthood.
