Предыдущая статья: Создание пустого проекта с помощью NestJS-mod
Создание приложения происходит через nx схематик для Angular.
Адрес сервера задается жестко в коде, в следующих постах адрес будет перенесен в переменные окружения.
Для запуска E2E-тестов используется "Playwright".
1. Устанавливаем необходимые библиотеки и создаем пустое Angular приложение
Команды
# Install all need main dev-dependencies
npm install --save-dev @nx/angular@19.5.3
# Create Angular application
./node_modules/.bin/nx g @nx/angular:application --directory=apps/client --name=client --projectNameAndRootFormat=as-provided --style=scss --ssr=true --viewEncapsulation=None --addTailwind=true --e2eTestRunner=playwright --bundler=webpack
Вывод консоли
$ npm install --save-dev @nx/angular@19.5.3
added 222 packages, removed 278 packages, changed 3 packages, and audited 2136 packages in 39s
292 packages are looking for funding
run `npm fund` for details
14 vulnerabilities (4 moderate, 10 high)
To address issues that do not require attention, run:
npm audit fix
To address all issues (including breaking changes), run:
npm audit fix --force
Run `npm audit` for details.
$ ./node_modules/.bin/nx g @nx/angular:application --directory=apps/client --name=client --projectNameAndRootFormat=as-provided --style=scss --ssr=true --viewEncapsulation=None --addTailwind=true --e2eTestRunner=playwright --bundler=webpack
NX Generating @nx/angular:application
Fetching @nx/playwright...
UPDATE .gitignore
UPDATE .prettierignore
UPDATE package.json
UPDATE nx.json
CREATE apps/client/project.json
CREATE apps/client/src/index.html
CREATE apps/client/src/styles.scss
CREATE apps/client/tsconfig.app.json
CREATE apps/client/tsconfig.editor.json
CREATE apps/client/tsconfig.json
CREATE apps/client/public/favicon.ico
CREATE apps/client/src/app/app.component.scss
CREATE apps/client/src/app/app.component.html
CREATE apps/client/src/app/app.component.spec.ts
CREATE apps/client/src/app/app.component.ts
CREATE apps/client/src/app/app.config.ts
CREATE apps/client/src/app/app.routes.ts
CREATE apps/client/src/app/nx-welcome.component.ts
CREATE apps/client/src/main.ts
CREATE apps/client/tailwind.config.js
CREATE apps/client/.eslintrc.json
CREATE apps/client/jest.config.ts
CREATE apps/client/src/test-setup.ts
CREATE apps/client/tsconfig.spec.json
CREATE apps/client-e2e/project.json
CREATE apps/client-e2e/src/example.spec.ts
CREATE apps/client-e2e/playwright.config.ts
CREATE apps/client-e2e/tsconfig.json
CREATE apps/client-e2e/.eslintrc.json
UPDATE .vscode/extensions.json
CREATE apps/client/src/main.server.ts
CREATE apps/client/src/app/app.config.server.ts
CREATE apps/client/tsconfig.server.json
CREATE apps/client/server.ts
npm WARN deprecated abab@2.0.6: Use your platform's native atob() and btoa() methods instead
npm WARN deprecated domexception@4.0.0: Use your platform's native DOMException instead
added 364 packages, removed 57 packages, changed 10 packages, and audited 2443 packages in 24s
297 packages are looking for funding
run `npm fund` for details
12 vulnerabilities (2 moderate, 10 high)
To address issues that do not require attention, run:
npm audit fix
To address all issues (including breaking changes), run:
npm audit fix --force
Run `npm audit` for details.
NX 👀 View Details of client
Run "nx show project client" to view details about this project.
2. Запускаем сборку всех проектов
Команды
# Build all applications and library
npm run build
Вывод консоли
$ npm run build
> @nestjs-mod-fullstack/source@0.0.0 build
> npm run generate && npm run tsc:lint && ./node_modules/.bin/nx run-many --exclude=@nestjs-mod-fullstack/source --all -t=build --skip-nx-cache=true
> @nestjs-mod-fullstack/source@0.0.0 generate
> ./node_modules/.bin/nx run-many --exclude=@nestjs-mod-fullstack/source --all -t=generate --skip-nx-cache=true && npm run make-ts-list && npm run lint:fix
NX Successfully ran target generate for 0 projects (37ms)
> @nestjs-mod-fullstack/source@0.0.0 make-ts-list
> ./node_modules/.bin/rucken make-ts-list
> @nestjs-mod-fullstack/source@0.0.0 lint:fix
> npm run tsc:lint && ./node_modules/.bin/nx run-many --exclude=@nestjs-mod-fullstack/source --all -t=lint --fix
> @nestjs-mod-fullstack/source@0.0.0 tsc:lint
> ./node_modules/.bin/tsc --noEmit -p tsconfig.base.json
apps/client/src/test-setup.ts:1:1 - error TS2578: Unused '@ts-expect-error' directive.
1 // @ts-expect-error https://thymikee.github.io/jest-preset-angular/docs/getting-started/test-environment
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Found 1 error in apps/client/src/test-setup.ts:1
3. Получаем ошибку "Unused '@ts-expect-error' directive." и решаем ее
Так как nx содержит множество различных шаблонов под разные фреймворки, часто можно встретить неявные ошибки которые не понятно как устранять, для обхода текущей ошибки просто перебьем типизацию и удалим директиву.
Обновленный файл apps/client/src/test-setup.ts
(globalThis as any).ngJest = {
testEnvironmentOptions: {
errorOnUnknownElements: true,
errorOnUnknownProperties: true,
},
};
import 'jest-preset-angular/setup-jest';
4. Повторно запускаем сборку всех проектов
Команды
# Build all applications and library
npm run build
Вывод консоли
$ npm run build
> @nestjs-mod-fullstack/source@0.0.0 build
> npm run generate && npm run tsc:lint && ./node_modules/.bin/nx run-many --exclude=@nestjs-mod-fullstack/source --all -t=build --skip-nx-cache=true
> @nestjs-mod-fullstack/source@0.0.0 generate
> ./node_modules/.bin/nx run-many --exclude=@nestjs-mod-fullstack/source --all -t=generate --skip-nx-cache=true && npm run make-ts-list && npm run lint:fix
NX Successfully ran target generate for 0 projects (25ms)
> @nestjs-mod-fullstack/source@0.0.0 make-ts-list
> ./node_modules/.bin/rucken make-ts-list
> @nestjs-mod-fullstack/source@0.0.0 lint:fix
> npm run tsc:lint && ./node_modules/.bin/nx run-many --exclude=@nestjs-mod-fullstack/source --all -t=lint --fix
> @nestjs-mod-fullstack/source@0.0.0 tsc:lint
> ./node_modules/.bin/tsc --noEmit -p tsconfig.base.json
✔ nx run server:lint [existing outputs match the cache, left as is]
✔ nx run server-e2e:lint [existing outputs match the cache, left as is]
✔ nx run client:lint (1s)
—————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
NX Successfully ran target lint for 3 projects (1s)
With additional flags:
--fix=true
Nx read the output from the cache instead of running the command for 2 out of 3 tasks.
> @nestjs-mod-fullstack/source@0.0.0 tsc:lint
> ./node_modules/.bin/tsc --noEmit -p tsconfig.base.json
✔ nx run server:build:production (3s)
✔ nx run client:build:production (15s)
—————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
NX Successfully ran target build for 2 projects (15s)
5. Добавляем команду в конфигурацию pm2 для запуска Angular приложения в режиме watch
Обновленная конфигурация pm2 ecosystem.config.json
{
"apps": [
{
"name": "server",
"script": "node ./dist/apps/server/main.js",
"node_args": "-r dotenv/config"
},
{
"name": "client",
"script": "./node_modules/.bin/nx serve client --host=0.0.0.0 --disable-host-check",
"node_args": "-r dotenv/config"
}
]
}
6. Запускаем все проекты в watch режиме через pm2
Команды
npm run pm2:start
Вывод консоли
$ npm run pm2:start
> @nestjs-mod-fullstack/source@0.0.0 pm2:start
> ./node_modules/.bin/pm2 start ./ecosystem.config.json
>>>> In-memory PM2 is out-of-date, do:
>>>> $ pm2 update
In memory PM2 version: 3.1.3
Local PM2 version: 5.4.2
[PM2][WARN] Applications server, client not running, starting...
[PM2] App [server] launched (1 instances)
[PM2] App [client] launched (1 instances)
┌────┬───────────┬─────────────┬─────────┬─────────┬──────────┬────────┬──────┬───────────┬──────────┬──────────┬──────────┬──────────┐
│ id │ name │ namespace │ version │ mode │ pid │ uptime │ ↺ │ status │ cpu │ mem │ user │ watching │
├────┼───────────┼─────────────┼─────────┼─────────┼──────────┼────────┼──────┼───────────┼──────────┼──────────┼──────────┼──────────┤
│ 1 │ client │ default │ N/A │ fork │ 454827 │ 0s │ 0 │ online │ 0% │ 13.2mb │ endy │ disabled │
│ 0 │ server │ default │ N/A │ fork │ 454826 │ 0s │ 0 │ online │ 0% │ 25.6mb │ endy │ disabled │
└────┴───────────┴─────────────┴─────────┴─────────┴──────────┴────────┴──────┴───────────┴──────────┴──────────┴──────────┴──────────┘
7. Запускаем юнит-тесты
Команды
npm run test
Вывод консоли
$ npm run test
> @nestjs-mod-fullstack/source@0.0.0 test
> ./node_modules/.bin/nx run-many --exclude=@nestjs-mod-fullstack/source --all -t=test --skip-nx-cache=true --passWithNoTests --output-style=stream-without-prefixes
> nx run client:test --passWithNoTests
> nx run server:test --passWithNoTests
NX Running target test for 2 projects
With additional flags:
--passWithNoTests=true
✔ nx run server:test (3s)
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
NX Running target test for 2 projects
With additional flags:
--passWithNoTests=true
→ Executing 1/1 remaining tasks...
✔ nx run client:test (3s)
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
NX Successfully ran target test for 2 projects (3s)
With additional flags:
--passWithNoTests=true
NX Nx detected a flaky task
server:test
Flaky tasks can disrupt your CI pipeline. Automatically retry them with Nx Cloud. Learn more at https://nx.dev/ci/features/flaky-tasks
8. Для запуска e2e-тестов на Angular необходимо установить дополнительные библиотекти
Команды
npx playwright install
Вывод консоли
$ npx playwright install
Downloading Chromium 128.0.6613.18 (playwright build v1129) from https://playwright.azureedge.net/builds/chromium/1129/chromium-linux.zip
162.8 MiB [====================] 100% 0.0s
Chromium 128.0.6613.18 (playwright build v1129) downloaded to /home/endy/.cache/ms-playwright/chromium-1129
Downloading FFMPEG playwright build v1009 from https://playwright.azureedge.net/builds/ffmpeg/1009/ffmpeg-linux.zip
2.6 MiB [====================] 100% 0.0s
FFMPEG playwright build v1009 downloaded to /home/endy/.cache/ms-playwright/ffmpeg-1009
Downloading Firefox 128.0 (playwright build v1458) from https://playwright.azureedge.net/builds/firefox/1458/firefox-ubuntu-20.04.zip
85.6 MiB [====================] 100% 0.0s
Firefox 128.0 (playwright build v1458) downloaded to /home/endy/.cache/ms-playwright/firefox-1458
Downloading Webkit 18.0 (playwright build v2051) from https://playwright.azureedge.net/builds/webkit/2051/webkit-ubuntu-20.04.zip
134.5 MiB [====================] 100% 0.0s
Webkit 18.0 (playwright build v2051) downloaded to /home/endy/.cache/ms-playwright/webkit-2051
9. Запускаем e2e-тесты
Команды
./node_modules/.bin/nx run-many --exclude=@nestjs-mod-fullstack/source --all -t=e2e --skip-nx-cache=true --output-style=stream-without-prefixes
Вывод консоли
$ ./node_modules/.bin/nx run-many --exclude=@nestjs-mod-fullstack/source --all -t=e2e --skip-nx-cache=true --output-style=stream-without-prefixes
> nx run client-e2e:e2e
> playwright test
NX Running target e2e for 2 projects and 1 task they depend on
NX Running target e2e for 2 projects and 1 task they depend on
→ Executing 1/3 remaining tasks...
⠇ nx run client-e2e:e2e
✔ nx run client-e2e:e2e (4s)
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
✔ nx run server:build:production (2s)
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
NX Running target e2e for 2 projects and 1 task they depend on
→ Executing 1/1 remaining tasks...
⠋ nx run server-e2e:e2e
✔ nx run server-e2e:e2e (2s)
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
NX Successfully ran target e2e for 2 projects and 1 task they depend on (8s)
10. Добавляем работу с хттп в Angular приложении
Обновленный конфиг apps/client/src/app/app.config.ts
import { ApplicationConfig, provideZoneChangeDetection } from '@angular/core';
import { provideRouter } from '@angular/router';
import { appRoutes } from './app.routes';
import { provideClientHydration } from '@angular/platform-browser';
import { provideHttpClient } from '@angular/common/http'; // <---
export const appConfig: ApplicationConfig = {
providers: [
provideClientHydration(),
provideZoneChangeDetection({ eventCoalescing: true }),
provideRouter(appRoutes),
provideHttpClient(), // <---
],
};
11. Добавляем получение данных с сервера и сохранение их в локальную переменную
Обновленный корневой typescript-файл apps/client/src/app/app.component.ts
import { Component, OnInit, ViewEncapsulation } from '@angular/core';
import { RouterModule } from '@angular/router';
import { NxWelcomeComponent } from './nx-welcome.component';
import { HttpClient } from '@angular/common/http';
@Component({
standalone: true,
imports: [NxWelcomeComponent, RouterModule],
selector: 'app-root',
templateUrl: './app.component.html',
styleUrl: './app.component.scss',
encapsulation: ViewEncapsulation.None,
})
export class AppComponent implements OnInit {
title = 'client';
serverMessage!: string;
constructor(private readonly httpClient: HttpClient) {}
ngOnInit() {
this.httpClient.get<{ message: string }>('http://localhost:3000/api').subscribe((result) => (this.serverMessage = result.message));
}
}
12. Добавляем отображение получение данных с сервера
Обновленный корневой html-файл apps/client/src/app/app.component.html
<app-nx-welcome></app-nx-welcome> <router-outlet></router-outlet>
<div id="serverMessage">{{ serverMessage }}</div>
13. Обновляем E2E-тест в котором проверяем получение и отображение данных с сервера
Обновленный файл с тестом apps/client-e2e/src/example.spec.ts
import { test, expect } from '@playwright/test';
test('has title', async ({ page }) => {
await page.goto('/');
// Expect h1 to contain a substring.
expect(await page.locator('h1').innerText()).toContain('Welcome');
});
test('has serverMessage', async ({ page }) => {
await page.goto('/');
// Expect h1 to contain a substring.
expect(await page.locator('#serverMessage').innerText()).toContain('Hello API');
});
14. Повторно запускаем e2e-тесты
Команды
./node_modules/.bin/nx run-many --exclude=@nestjs-mod-fullstack/source --all -t=e2e --skip-nx-cache=true --output-style=stream-without-prefixes
Вывод консоли
$ ./node_modules/.bin/nx run-many --exclude=@nestjs-mod-fullstack/source --all -t=e2e --skip-nx-cache=true --output-style=stream-without-prefixes
> nx run client-e2e:e2e
> playwright test
NX Running target e2e for 2 projects and 1 task they depend on
NX Running target e2e for 2 projects and 1 task they depend on
→ Executing 1/3 remaining tasks...
⠹ nx run client-e2e:e2e
✔ nx run client-e2e:e2e (5s)
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
✔ nx run server:build:production (3s)
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
NX Running target e2e for 2 projects and 1 task they depend on
→ Executing 1/1 remaining tasks...
⠦ nx run server-e2e:e2e
✔ nx run server-e2e:e2e (2s)
————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————————
NX Successfully ran target e2e for 2 projects and 1 task they depend on (10s)
15. Останавливаем pm2 проекты
Команды
npm run pm2:stop
Вывод консоли
$ npm run pm2:stop
> @nestjs-mod-fullstack/source@0.0.0 pm2:stop
> ./node_modules/.bin/pm2 delete all
>>>> In-memory PM2 is out-of-date, do:
>>>> $ pm2 update
In memory PM2 version: 3.1.3
Local PM2 version: 5.4.2
[PM2] Applying action deleteProcessId on app [all](ids: [ 0, 1 ])
[PM2] [server](0) ✓
[PM2] [client](1) ✓
┌────┬───────────┬─────────────┬─────────┬─────────┬──────────┬────────┬──────┬───────────┬──────────┬──────────┬──────────┬──────────┐
│ id │ name │ namespace │ version │ mode │ pid │ uptime │ ↺ │ status │ cpu │ mem │ user │ watching │
└────┴───────────┴─────────────┴─────────┴─────────┴──────────┴────────┴──────┴───────────┴──────────┴──────────┴──────────┴──────────┘
В посте нет картинок, работа приложений проверяется через тесты, но если кому то нужно видеть результат, то ответ сервера можно получить по адресу: http://localhost:3000/api, а ответ клиента по адресу: http://localhost:4200/
В следующем посте я добавлю докер образ с базой данных Postgres и написание и запуск миграций через Flyway...
Ссылки
https://nestjs.com - официальный сайт фреймворка
https://nestjs-mod.com - официальный сайт дополнительных утилит
https://github.com/nestjs-mod/nestjs-mod-fullstack - проект из поста
https://github.com/nestjs-mod/nestjs-mod-fullstack/commit/32bcd1171985f5bd22e10b67c6b179807ef75cfc - коммит на текущие изменения
