Как-то понадобилось добавить в проект симпатичный 3-d pie график.
Пока толпа решала на какой компонент потратить денежку, нарисовал вот такой вот график:

Кому надо, делюсь кодом прототипа, он минимален:
Берите, не стесняйтесь =)
Пока толпа решала на какой компонент потратить денежку, нарисовал вот такой вот график:

Кому надо, делюсь кодом прототипа, он минимален:
private static void Draw3DPie(int[] sectors, PaintEventArgs e)
{
const int x = 50;
const int y = 50;
int width = 300;
int height = 120;
int sideHeight = 40;
e.Graphics.SmoothingMode = SmoothingMode.AntiAlias;
int sectorId = 0;
float startAngle = 0x0;
bool hidenSide = false;
foreach(int sector in sectors) {
Random rnd = new Random( (int) ( sector + DateTime.Now.Ticks + sectorId++) );
Color color = Color.FromArgb(
rnd.Next(0, 255),
rnd.Next(0, 255),
rnd.Next(0, 255)
);
if(!hidenSide) {
GraphicsPath path = new GraphicsPath();
GraphicsPath buff = new GraphicsPath();
float angleBeizier = sector;
if( startAngle + sector >= 180 ) {
angleBeizier = 180 - startAngle;
hidenSide = true;
}
path.AddArc(x, y, width, height, startAngle, angleBeizier);
buff.AddArc(x, y + sideHeight, width, height, startAngle, angleBeizier);
buff.Reverse();
path.AddPath(buff, true);
// Drawing 3d sides
e.Graphics.FillPath(new SolidBrush(color), path);
e.Graphics.FillPath(new SolidBrush(Color.FromArgb(81,0,0,0)), path);
e.Graphics.DrawPath(new Pen(new SolidBrush(Color.Silver), 1), path);
}
// Drawing top side
e.Graphics.FillPie(new SolidBrush(color), x, y, width, height, startAngle, sector);
e.Graphics.DrawPie(new Pen(new SolidBrush(Color.Silver), 1), x, y, width, height, startAngle, sector);
startAngle += sector;
}
}
* This source code was highlighted with Source Code Highlighter.
Берите, не стесняйтесь =)
